Description & Specifications
A scalable 5-bay data-management platform with dual 2.5GbE, optional 10GbE, SSD caching, and comprehensive Synology DSM services.
- Up to 1,181 MB/s read and 1,116 MB/s write performance
- Dual 2.5GbE LAN plus support for an optional 10GbE upgrade module
- 4 GB DDR4 memory, expandable up to 32 GB
- 2 x M.2 NVMe slots for SSD cache or supported storage pools
- Expandable from 5 to 15 drive bays with two optional DX525 units
- Powered by Synology DiskStation Manager (DSM)
Key specifications
| Processor | AMD Ryzen V1500B, 4-core / 8-thread, 2.2 GHz |
|---|---|
| Drive bays | 5 x 3.5-inch SATA HDD or 2.5-inch SATA SSD |
| Maximum bays | 15 with 2 x DX525 expansion units |
| Network | 2 x 2.5GbE RJ-45; optional E10G22-T1-Mini 10GbE module |
| External ports | 2 x USB 3.2 Gen 1, 2 x USB Type-C expansion ports |
| Dimensions / weight | 166 x 230 x 223 mm / 2.67 kg |
| Warranty | 3 years; extension to 5 years available in select markets |
Ready for growing workloads
Use Synology DSM for centralized file services, private cloud collaboration, Active Backup Suite, Hyper Backup, snapshots, virtualization, photo management, and video surveillance. Two Surveillance Station device licenses are included.
Store, share, and protect
- Private cloud: Access and synchronize files across locations and devices, with versioning for straightforward recovery.
- License-free backup tools: Protect PCs, servers, virtual machines, Microsoft 365, Google Workspace, and other Synology systems from one console.
- Multi-site workflows: Keep files synchronized between offices or combine local NAS performance with cloud-based Hybrid Share.
- Virtualization: Use certified storage integration or run supported containers and virtual machines directly on the NAS.
- Video surveillance: Build a private NVR with support for more than 8,700 camera models and two included device licenses.
Storage and RAID
Supports Btrfs and ext4 internal file systems, hot-swappable SATA drives, M.2 SSD cache or supported storage pools, and Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, and RAID 10.
In the box
- DS1525neo+ main unit
- Accessory pack
- 120 W power adapter and AC power cord
- 2 x RJ-45 LAN cables
Why buy from PNP Storage?
PNP (Peripherals and Parts) is a Synology Sub-distributor and Authorized Service Partner in Dubai, serving UAE businesses and home users since 2005.
- Pre-sales sizing for drives, RAID, memory, SSD cache, 10GbE, backup, virtualization, and surveillance
- Deployment guidance, capacity upgrades, data migration, and security best-practice services
- Local warranty and failed-device assistance for eligible UAE-channel products
- Optional warranty extension and Next Business Day replacement plans may be available
- Free UAE delivery for qualifying online retail orders, subject to PNP delivery terms
Frequently asked questions
Are hard drives included?
No. This listing is for the NAS enclosure unless the product title or selected bundle states otherwise.
Does it support 10GbE?
Yes. A compatible optional E10G22-T1-Mini network upgrade module adds 10GbE connectivity.
Can the DS1525neo+ grow later?
Yes. Two optional DX525 units expand the system from 5 to 15 drive bays.
Please note: Storage drives, M.2 SSDs, network upgrade module, and DX525 expansion units are sold separately. Compatible drives are required. Performance and usable capacity vary by drive, RAID configuration, network, and workload.
