Thumbnail for QNAP Thunderbolt 3 to 10GbE Adapter

All Pictures shown are for illustration purpose only.Actual product may vary in color,shape, size or otherwise

QNAP Thunderbolt 3 to 10GbE Adapter

Call for price

Brand: QNAP MPN: Qnap_Thunderbolt_3_to_10GbE_Adapter

⬤

Price on Request

This product is not priced online. Please contact us for a quote.

Returns and Refund Privacy Policy

Product information for Qnap_Thunderbolt_3_to_10GbE_Adapter

Product details

Thunderbolt 3 to 10GbE Adapter

Connect to 10GbE networks over Thunderbolt 3

The QNAP QNA series is a cost-effective Thunderbolt 3 to 10GbE adapter that empowers your Mac or Windows computers with blazing-fast 10GbE network connectivity using a Thunderbolt 3 type-C port. With the portable QNA series adapter, a 10GbE network can be created between your Thunderbolt 3 computer and another 10GbE-capable device or NAS to facilitate high-speed data transfer for large files and help to streamline collaborative workflows to improve efficiency.

Note:
Windows devices: The driver for the Aquantia AQC107 is required to use the QNA-T310G1T. The driver for the Aquantia AQC100 is required to use the QNA-T310G1S.
Mac devices: Requires macOS 10.13.3 (or later).

10GbE data transfer that media professionals need

As video resolutions move from 1080p, to 4K, 8K (and beyond) media creators are struggling with the storage and network requirements needed for editing huge multimedia files. The QNA series comes with two models. The QNA-T310G1T features a Thunderbolt 3 to 10GbE Multi-Gigabit (10G/5G/2.5G/1G/100M) port, and the QNA-T310G1S features one 10GbE SFP+ port, allowing you to easily add 10GbE connectivity to any Thunderbolt 3 device. Coupled with a QNAP 10GbE switch, a budget-friendly 10GbE environment can be created for creative studios to benefit from the incredible speed and bandwidth that 10GbE provides.

Stylish

The QNA series features a metallic bright-toned cover that fits perfectly alongside other devices.
Portable

The QNA series requires no extra power supply, and you can easily carry it around for universal deployment.
Heat Dissipation

The QNA series has shallow grooves on its top for effective heat dissipation.

Effortless setup

Simply connect a QNA adapter to your Mac or Windows computer using the included Thunderbolt 3 cable and connect the adapter to a 10GbE-capable switch, NAS, or other device using a 10GbE cable (RJ45 Cat 5e/Cat 6a cable or above or a SFP+ DAC).

Available Models

QNA-T310G1T	PHY IC: AQC107S I/O: 1 x Thunderbolt 3, 1 x 10GbE/NBASE-T connector Package content: QNA-T310G1T, 0.5M Thunderbolt 3 cable and manual Port and cable: RJ-45; Cat 6a cable recommended Note: Windows devices: The driver for the Aquantia AQC107 is required to use the QNA-T310G1T. Mac devices: Requires macOS 10.13.3 (or later).
QNA-T310G1S	PHY IC: AQC100S I/O: 1 x Thunderbolt 3, 1 x 10GbE SFP+ connector Package content: QNA-T310G1S, 0.5M Thunderbolt 3 cable and manual. Port and cable: SFP+; SFP+ direct attach cable recommended Note: Windows devices: The driver for the Aquantia AQC100 is required to use the QNA-T310G1S. Mac devices: Requires macOS 10.13.3 (or later).

How to set the MTU

Mac: Open System Preferences go to Network Select the QNA Thunderbolt Ethernet click Advanced... go to the Hardware tab change Configure to Manually set MTU to 9000.

Windows: Open 'Settings' go to 'Network & Internet' click 'Change your adapter options' right click on the Thunderbolt 3 Ethernet adapter and click 'Properties' click 'Configure...' go to the 'Advanced' tab select 'Jumbo Frame' and set the value to '9KB MTU'.

NAS: Open 'Network & Virtual Switch' go to 'Network' > 'Interfaces' find the applicable Ethernet adapter, click and select 'Configure' go to the 'IPv4' tab set 'Jumbo Frame' to 9000.

Interface	Single-port Thunderbolt 3 to single-port 10GbE NBASE-T RJ-45
Data Transfer	10Gbps; 5Gbps; 2.5Gbps; 1Gbps; 100Mbps
Cables	Thunderbolt 3: Thunderbolt 3 cable Network Cable: CAT 5e, CAT 6, CAT 6A, CAT 7 * 0.5M Thunderbolt3 40Gb/s cable x 1 included * Suggest using CAT 6 (or above) cable to achieve 10GbE transfer speed
Power Supply Unit	Bus powered
System Requirements (Windows)	Windows 7 (64-bit) / Windows 10 (64-bit) * Required download Aquantia * Required a Thunderbolt 3 port on your computer
System Requirements (Mac)	macOS 10.13.3 (or later) * Required a Thunderbolt 3 port on your computer
System Requirements (QNAP NAS)	QNAP Thunderbolt 3 NAS (will be supported in Q4/2018)
Operating Temperature & Relative Humidity	100M CAT 6A: 35 50M CAT 6A: 40 5~95% (non-condensing)
Dimensions (H x W x D)	27.6 x 56 x 112 mm 1.08 x 2.20 x 4.41 inch
Weight	Net weight: 0.19Kg, Gross weight: 0.36Kg
LED Indicators	Power, LAN Link/Act, transfer speed
Package Contents	QNA-T310G1T, 0.5M Thunderbolt 3 cable x 1, installation guide

Buying and delivery notes

Contact us for current stock, lead time, and bulk pricing.
We ship across Dubai, Abu Dhabi, Sharjah, and the rest of the UAE.
Export shipping can be arranged for customers in the Middle East and Africa.
