Description & Specifications
Every Port Has a Purpose
Need to plug in headphones during a call? Front panel. Charging your phone while editing? Front USB port. External drives and Ethernet? Hidden in back where cables belong. It's the difference between thoughtful design and just cramming ports wherever they fit.
Maximum Port Variety
14 different ports handle everything from vintage USB drives to cutting-edge Thunderbolt displays
Purposefully Designed
Frequently used ports up front (headphones, SD cards, phone charging) while permanent connections stay hidden in back
Plenty of Power
Keep your notebook energized all day while running 13 other connected devices simultaneously with 85 watts of power
Connect Your Entire Creative Arsenal
Two Thunderbolt ports handle your fastest drives, displays, and future devices
Modern Device Ready
High-speed USB-C for your latest phone, tablet, or external SSD without blocking Thunderbolt ports
Never Leave a Device Behind
Five USB-A ports for keyboards, mice, webcams, hard drives, and all those devices you still need
Extra Display Freedom
Dedicated DisplayPort for that third monitor or projector presentation without stealing Thunderbolt bandwidth
Upload Without the Wait
Conduct large file transfers fast and enjoy rock-solid video calls with Gigabit Ethernet
Studio-Grade Audio Out
Connect professional audio interfaces and high-end speakers with digital precision
Instant Audio Access
Front-panel headphone jack for quick listening and microphone input for clear calls
Never Hunt for Chargers Again
Your laptop stays charged, your phone tops off, and your tablet gets power from ports that deliver serious juice, not the trickle charge you get from cheap hubs. Throw that tangle of power adapters in a drawer and forget about outlet wars at coffee shops.
Disconnect In One Click
OWC Dock Ejector safely disconnects all connected drives in a single click. Designed by OWC hardware and software engineers, Dock Ejector ensures all data is written before disconnection, saving time and protecting against data loss. Use it to move quickly between workstations and get the most out of your 14-Port Thunderbolt Dock. Learn More
Built to Survive Your Workflow
This isn't another plastic box that breaks after three months. Solid aluminum construction handles daily abuse while looking professional enough for client meetings. The ports that get used most are exactly where your hands expect them to be.
Create A Tablet ProStation
While iPad Pros and other tablet computers offer awesome content creation potential, they’re handcuffed by limited internal storage, display size, and often a single Thunderbolt (USB-C) port. Instead of lugging around a bulky notebook or worse, being chained to a non-portable desktop workstation, capture what you need on the fly with a tablet. Back at a desk, transform that tablet into a “prostation” with an external display, keyboard, mouse, and external drive all connected to this dock.
Pro-tips: Daisy-chaining With Thunderbolt Devices
With the ability to run up to six devices per port, Thunderbolt ports amplify your laptop or desktop with peripheral power. Learn the basics of daisy-chaining Thunderbolt devices for maximum performance in this handy infographic. View Infographic
OWC Thunderbolt 3 Cables
A Thunderbolt 3 cable is included with the OWC 14-Port Thunderbolt Dock, but if your workflow demands a longer cable to make the connection, OWC Premium Thunderbolt 3 (USB-C) Cables are the perfect choice.
Innergize Your Workflow with Highest Performance and Reliability
OWC Innergize™ is the first stage of the Capture to Completion™ ecosystem of OWC products designed to seamlessly propel professional photographers, videographers, and content creators to the highest level of workflow performance and reliability. This OWC custom-designed app is a complete health, performance, and field upgrade management tool when using OWC Atlas memory cards with OWC Atlas readers and reader equipped products.
Work with Maximum Confidence and Reliability
Health
Over time and use cycles, flash memory does wear out. Innergize verifies and reports the percentage of use life remaining. Now you can work with full confidence your OWC flash memory product will deliver the reliability you can trust.
Sanitize
Writes, deletes, and formatting all take their toll on memory cards. Innergize cleans and restores the flash memory performance of OWC memory cards so you can get the best results on every use.
Field Upgrade
When new cameras or firmware updates to existing cameras are introduced, they may not work properly with flash memory cards and drives. Innergize gives OWC memory card users the ability to quickly upgrade their firmware in the field for full compatibility, additional performance enhancements, and bug fixes for optimal reliability.
- Both the SD card reader and the microSD card reader are controlled by the same chipset, meaning only one can be in use at a time.
- Resolutions and refresh rates will vary depending upon hardware, connections, and OS being utilized. Dock does not support display daisy-chains via MST (Multi-Stream Transport).
- Native Thunderbolt 3 display or Thunderbolt/Thunderbolt 2 display using the Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter.
-
Device Ports
- (1) Host Port - Thunderbolt 3 (USB-C) up to 40Gb/s (5000MB/s)
- (1) Thunderbolt 3 (USB-C) Port
- (1) USB 3.2 Gen 2 Type-C Port up to 10Gb/s (1250MB/s) - USB 2.0/3.0 backwards compatible
- (5) USB 3.2 Gen 1 Type-A Ports up to 600MB/s
- (1) Mini DisplayPort Port
- (1) Gigabit Ethernet (GbE) RJ45 Port
- (1) S/PDIF Digital Audio Output Port
- (1) 3.5mm Stereo Audio Input/Output Combo Port
Memory Card Slots
- (1) microSD
- (1) SD
Power Delivery
- Thunderbolt 3 host port provides up to 85W of power to the host computer
Additional Ports
- None
UASP Support
- UASP (USB Attached SCSI Protocol) is supported
-
Display Support
- Up to one 5K display @ 60Hz,
- or two 4K displays @ 60Hz
Display Support by Port
- Thunderbolt 3: Up to 5K @ 60Hz via a native Thunderbolt 3 display or 4K @ 60Hz via a Thunderbolt display or a USB-C display adapter
- Mini DisplayPort 1.2: Up to 4K @ 60Hz
-
Ethernet Speeds (RJ45)
- 1Gb/s "Gigabit" (1000BASE-T)
- 100Mb/s (100BASE-T)
- 10Mb/s (10BASE-T)
Jumbo Frame Support
- Yes
Chipset / Controller
- Thunderbolt 3 - Intel JHL6540
- USB Type-C - ASMedia ASM1142
- USB Type-A - Fresco Logic FL1100EX (x2)
- Ethernet - Intel i210
- S/PDIF Audio - C Media CM6533
- Headphone / Mic - C Media CM6533
- SD 4.0 Slot - Genesys Logic GL3227
- Mini DisplayPort DP++ - Parade PS181
-
External Power Adapter
- Yes
Power Supply
- External UL-listed universal auto-switching power supply
- Need an additional power supply? Secondary/replacement power supplies may also be available.
AC Input
- 120-240V, 50-60Hz, 2.5A
DC Output
- +20V, 9A
Wattage
- 180W
-
Security Slot
- No
Housing Color
- Chassis: Space Gray
- Covers: Black
Housing Material
- Chassis: Aluminum
- Covers: Polycarbonate
Dimensions
- Height: 2.5 cm (1.0 in)
- Length: 8.9 cm (3.5 in)
- Width: 23.0 cm (9.1 in)
Weight
- 500.0 g (1.10 lbs)
-
Certifications
- CE
- FCC
RoHS Compliant
- Yes
Reach Certification
- Yes
UPC
- 810586030540
-
Ambient Temperature
- Operating: 32°F to 104°F (0°C to 40°C)
- Non-Operating: -4°F to 158°F (-20°C to 70°C)
Altitude
- Operating: -304.8 m to 3,048.0 m (-1,000 ft to 10,000 ft)
- Non-Operating: -304.8 m to 12,192.0 m (-1,000 ft to 40,000 ft)
Host Interface Requirements
- Thunderbolt (USB-C) port (backward compatible with Thunderbolt 2/Thunderbolt1)
Mac OS Compatibility
- macOS 10.12 Sierra
- macOS 10.13 High Sierra
- macOS 10.14 Mojave
- macOS 10.15 Catalina
- macOS 11.x Big Sur
- macOS 12.x Monterey
- macOS 13.x Ventura
- macOS 14.x Sonoma
- macOS 15.x Sequoia
- macOS 26.x Tahoe
PC OS Compatibility
- Windows 10 32-bit Edition
- Windows 10 64-bit Edition
- Windows Server 2016
- Windows 11
Mobile OS Compatibility
- iPadOS 14
- iPadOS 15
- iPadOS 16
- iPadOS 17
- iPadOS 18
- iPadOS 26
Driver Required
- Download Driver
- High-power USB support is required for compatibility with the Apple SuperDrive and Apple USB keyboard, and is required to enable high-speed charging for Apple iPads, iPhones and other higher-power capable devices. To enable high-power USB support please download the appropriate app and driver bundle.
- (1) OWC 14-Port Thunderbolt Dock
- (1) 0.7M (28") Thunderbolt Cable
- (1) External Power Supply and Power Cable
- (1) Quick Start Guide for OWC 14-Port Thunderbolt Dock
- (1) User Guide for OWC 14-Port Thunderbolt Dock
- (1) OWC Dock Ejector for Mac and Windows (software download)
- (1) User Guide for OWC Dock Ejector
- 2 Year OWC Limited Warranty
